Slitting Line

Slitting Line

General Technical Specification
Coil Material	CR/HR
Maximum Weight of Coil	25 Ton.
Maximum Coil Width	1220 MM
Minimum Coil Width	900 MM
Maximum Coil Thickness	4.0 MM
Minimum Coil Thickness	1.0 MM
Line Direction	To be decide by later
Total Power	100 HP
Total Approx. Line Length	60 FIT.

Hydrulic Decoiler QTY: - 2 Pcs.
Coil Material To be Loaded	CR/HR
Maximum Weight of Coil	25 Ton
Maximum Coil Width	1220 MM
Minimum Coil Width	900 MM
Maximum Coil Thickness	4.0 MM
Minimum Coil Thickness	1.0 MM
Type	Hydraulic
Motor H. P	10 HP, 1500 RPM
Maximum OD of Coil	1200 MM
Minimum ID of Coil	510-610 MM

Plan Shearing QTY: - 1 Pcs.
Working Capacity	1.0 – 4.0 MM
Type	Hydraulic
Cutting Blade Material	WPS with Hardness
Accuracy Level	1 MM
Pump / Filter / Motor	ABB Make
With Gard Film	Roll

Recoiler QTY: - 1 Pcs.
Coil Material To be Recoil	HR/CR
Maximum Weight of Coil	15 Ton
Type	Hydraulic
Motor H. P	40 HP, 1500 RPM

Slltter Head QTY : - 1 Pcs.
No of Work Station	1
Maximum Coil Width	1220 MM
Minimum Coil Width	900 MM
Maximum Coil Thickness	4.0 MM
Minimum Coil Thickness	1.0 MM
Shaft Material	Alloy Steel EN-31
Cutter Material	D2 with Hardness
Motor	10 HP ABB
Base Construction	Mild Steel

Hydraulic Power Pack QTY: - 1 Pcs.
Tank Capacity	200 Ltr
Motor	10 HP
Motor RPM	1440 RPM

Leveller QTY : - 1 Pcs.
No of Roller	15
Maximum Coil Width	1220 MM
Minimum Coil Width	900 MM
Maximum Coil Thickness	4.0 MM
Minimum Coil Thickness	1.0 MM
Shaft Material	Alloy Steel EN-8
Motor	20 HP ABB
Base Construction	Mild Steel

Electric Control Pannel
QTY: - 3 Pcs.
PLC	Touch Win
Touch Screen HMI	Delta
MCB / Relay Card / Push Button	Schneider
SMPS Range	12 Amp.
Input /Output Module	Schneider

Standard Accessories
SNABER DECOILER	1 Unit
LOOP	4 No.
LOOP TABLE	2 Unit
FAL PRESS	1 No,
DEBURING ROLL	1No
RECOILER OVERAM UNIT	1 No
COIL CAR	2 No
Entry Gate	2 No
